首页 产品展示 10.8英寸-18.5英寸 TFT LCD 13.3英寸 LCD RG133BFH-01 13.3英寸1920x1080 IPS TFT LCD
| Feature | Specification | Unit |
|---|---|---|
| Brand | Ronen | - |
| Size | 13.3 | inch |
| Resolution | 1920×1080 | dots |
| Pixel pitch | 0.153(W)x 0.153(H) | mm |
| Display Mode | IPS/NB | - |
| Viewing Direction | ALL | o'clock |
| Gray Scale Inversion Direction | ALL | o'clock |
| Luminance | 280 | cd/m2 |
| LCM (W * H * D) | 300.26X188.25X2.6 | mm |
| Active Area (W * H ) | 293.76x165.24 | mm |
| With /Without TP | Without TP | - |
| LED Numbers | 9S4P-LED | pcs |
| Operation temperature | -20~+70 | ℃ |
| Storage temperature | -30~+80 | ℃ |
| Interface | eDP | - |
| LCM Power Supply | 3.3 | V |
| LED Power Supply | 27.0 | V |
| Color Depth | 16.7M | - |
