首页 产品展示 0.9英寸-1.8英寸 TFT LCD 0.9英寸 LCD RG009GES-13 0.9英寸 TFT LCD 80*160 262K彩色显
| Feature | Specification | Unit |
|---|---|---|
| Brand | Ronen | - |
| Size | 0.9 | inch |
| Resolution | 80*160 | dots |
| Pixel pitch | 0.144(H)*0.126(V) | mm |
| Display Mode | TN/NW | - |
| Viewing Direction | 6 | o'clock |
| Gray Scale Inversion Direction | 12 | o'clock |
| Luminance | 100 | cd/m2 |
| LCM (W * H * D) | 15.80*27.00*1.66 | mm |
| Active Area (W * H ) | 11.52*20.16 | mm |
| With /Without TP | Without TP | - |
| LED Numbers | 1-LED | pcs |
| Operation temperature | -20~+70 | ℃ |
| Storage temperature | -30~+80 | ℃ |
| Interface | 4-wire-SPI 33PIN | - |
| LCM Power Supply | 2.8 | V |
| LED Power Supply | 3.0 | V |
| Color Depth | 262K | - |
| LCM Driver IC | ST7735S | - |
