首页 产品展示 4.3英寸-6.8英寸 TFT LCD 5英寸 LCD RG050BPS-01CP 5英寸 480x272 LCD带光学胶全贴合电容触摸
| Feature | Specification | Unit |
|---|---|---|
| Brand | Ronen | - |
| Size | 5.0 | inch |
| Resolution | 480*272 | dots |
| Pixel pitch | 0.231(H)x0.231(V) | mm |
| Display Mode | TN | - |
| Viewing Direction | 12 | o'clock |
| Gray Scale Inversion Direction | 6 | o'clock |
| Luminance | 350 | cd/m2 |
| LCM (W * H * D) | 120.70*75.80*4.50 | mm |
| Active Area (W * H ) | 110.88*62.83 | mm |
| With /Without TP | With CTP | - |
| LED Numbers | 6S2P-LED | pcs |
| Operation temperature | -20~+70 | ℃ |
| Storage temperature | -30~+80 | ℃ |
| Interface | RGB888/40PIN | - |
| LCM Power Supply | 3.3 | V |
| LED Power Supply | 18.0 | V |
| Color Depth | 16.7M | - |
| LCM Driver IC | ST7257 | - |
| CTP Dricer IC | GT911 | - |
