  • RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块
  • RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块
  • RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块
RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块

RG101BAH-09CP 10.1英寸1024x600带电容触摸屏TFT LCD模块

  • 产品项目 : RG101BAH-09CP
  • 类别: 10.1英寸 LCD
  • Resolution: 1024*(RGB)*600
  • Luminance: 320nits
  • LCM (W * H * D): 235.00*143.00*7.25mm
  • LCM Driver IC: HX8282+HX8696
  • 询价   邮件
产品描述:
Feature Specification Unit
Brand Ronen -
Size 10.1 inch
Resolution 1024*600 dots
Pixel pitch 0.2175(H)*0.2088(V) mm
Display Mode TN/NW -
Viewing Direction 12 o'clock
Gray Scale Inversion Direction 6 o'clock
Luminance 320 cd/m2
LCM (W * H * D) 235.00*143.00*7.25 mm
Active Area (W * H ) 222.72*125.28 mm
With /Without TP With CTP -
LED Numbers 3S13P-LED pcs
Operation temperature -20~+70
Storage temperature -30~+80
Interface RGB-24bit/50PIN -
LCM Power Supply 3.3 V
LED  Power Supply 9.0 V
Color Depth 16.7M -
LCM Driver IC HX8282+HX8696 -
CTP  Dricer IC GT928 -
