首页 产品展示 2英寸-2.8英寸 TFT LCD 2英寸 LCD RG020HQS-04 2英寸 240x320 IPS TFT HX8340B
Feature | Specification | Unit |
---|---|---|
Brand | Ronen | - |
Size | 1.77 | inch |
Resolution | 160*128 | dots |
Pixel pitch | 0.1992(H)*0.2070(V) | mm |
Display Mode | TN/NW | - |
Viewing Direction | 7:50 | o'clock |
Gray Scale Inversion Direction | - | o'clock |
Luminance | 110 | cd/m2 |
LCM (W * H * D) | 40.77*36.20*2.20 | mm |
Active Area (W * H ) | 35.28*27.71 | mm |
With /Without TP | Without TP | - |
LED Numbers | 3P-LED | pcs |
Operation temperature | -20~+70 | ℃ |
Storage temperature | -30~+80 | ℃ |
Interface | 8/16BIT MCU | - |
LCM Power Supply | 3.3 | V |
LED Power Supply | 3.0 | V |
Color Depth | 262K | - |
LCM Driver IC | HX8340B | - |
