首页 产品展示 7英寸-10.4英寸 TFT LCD 8.8英寸 LCD RG088BZHA-01 8.8英寸1280x480带LVDS接口IPS LCD
| Feature | Specification | Unit |
|---|---|---|
| Brand | Ronen | - |
| Size | 8.8 | inch |
| Resolution | 1280×480 | dots |
| Pixel pitch | 0.1635(W)x 0.1635(H) | mm |
| Display Mode | IPS/NB | - |
| Viewing Direction | ALL | o'clock |
| Gray Scale Inversion Direction | ALL | o'clock |
| Luminance | 400 | cd/m2 |
| LCM (W * H * D) | 229.6X97.3X6.0 | mm |
| Active Area (W * H ) | 209.28X78.48 | mm |
| With /Without TP | Without TP | - |
| LED Numbers | 3S9P-LED | pcs |
| Operation temperature | -10~+50 | ℃ |
| Storage temperature | -20~+60 | ℃ |
| Interface | LVDS/40PIN | - |
| LCM Power Supply | 3.3 | V |
| LED Power Supply | 9.0 | V |
| Color Depth | 16.7M | - |
