首页 产品展示 7英寸-10.4英寸 TFT LCD 10.1英寸 LCD RG101BYH-01CP 10.1英寸800x1280高亮全视角带电容触摸屏
| Feature | Specification | Unit |
|---|---|---|
| Brand | Ronen | - |
| Size | 10.1 | inch |
| Resolution | 800*1280 | dots |
| Pixel pitch | 0.2175(H)*0.2088(V) | mm |
| Display Mode | IPS/NB | - |
| Viewing Direction | ALL | o'clock |
| Gray Scale Inversion Direction | ALL | o'clock |
| Luminance | 720 | cd/m2 |
| LCM (W * H * D) | 168.73*254.50*8.10 | mm |
| Active Area (W * H ) | 135.36*216.58 | mm |
| With /Without TP | With CTP | - |
| LED Numbers | 6S7P-LED | pcs |
| Operation temperature | -20~+70 | ℃ |
| Storage temperature | -30~+80 | ℃ |
| Interface | MIPI | - |
| LCM Power Supply | 2.8 | V |
| LED Power Supply | 18.0 | V |
| Color Depth | 16.7M | - |
| LCM Driver IC | HX8394D | - |
| CTP Dricer IC | EXC80W32 | - |
