首页 产品展示 10.8英寸-18.5英寸 TFT LCD 12.1英寸 LCD RG121HXXA-03 12.1英寸1024x768带LVDS接口XGA IP
| Feature | Specification | Unit |
|---|---|---|
| Brand | Ronen | - |
| Size | 12.1 | inch |
| Resolution | 1024 x 768 | dots |
| Pixel pitch | 0.24(H)×0.24(V) | mm |
| Display Mode | IPS/NB | - |
| Viewing Direction | ALL | o'clock |
| Gray Scale Inversion Direction | ALL | o'clock |
| Luminance | 500 | cd/m2 |
| LCM (W * H * D) | 260.50*204.00*8.30 | mm |
| Active Area (W * H ) | 245.76*184.32 | mm |
| With /Without TP | Without TP | - |
| LED Numbers | 11S4P-LED | pcs |
| Operation temperature | -20~+70 | ℃ |
| Storage temperature | -30~+80 | ℃ |
| Interface | LVDS | - |
| LCM Power Supply | 3.3 | V |
| LED Power Supply | 36.3 | V |
| Color Depth | 16.7M | - |
