RG-T035BHSA-01 — 3.5″ 320x480 IPS TFT LCD Module
Industrial-grade display module from RONEN’s 23,700㎡ ISO 9001:2015 factory. Datasheet & samples available on request.
3.5"320x480IPS320 cd/m²Without touch
| RONEN P/N | RG-T035BHSA-01 |
|---|---|
| Display Size | 3.5 inch |
| Resolution | 320x480 |
| LCD Type / Shape | IPS |
| Luminance | 320 cd/m² |
| Module Interface | RGB/MCU/SPI 50PIN |
| LCD Driver IC | ST7365P |
| Touch Option | Without touch |
| Active Area (mm) | 48.96x73.44 |
| Outline Dim. (mm) | 54.48x84.71x2.20 |
| Operating Temp. (°C) | -20-70 |
| Storage Temp. (°C) | -30-80 |
Request a quote & datasheet
Full spec sheet, pricing and lead time for this model — factory-direct, no middleman.
- Standard stock193 models ready to ship, no MOQ
- Custom optionInterface / touch / brightness / outline tailored
- Lead timeStock items: 24–48h · Custom: 5–8 weeks
- Warranty12 months against DOA, 3-year longevity commitment
Similar Modules in 3 – 5 inch
RG-T035BQSA-01
3.5"240x320IPS
RG-T035SHI-01
3.5"320x480TN
RG-T035BHSA-01P
3.5"320x480IPS
RG-T035QHI-28
